DA97-07603B Genuine OEM Samsung Refrigerator Ice Maker
The DA97-07603B is a genuine Samsung OEM ice maker assembly for Samsung and select Maytag refrigerators. This is the freezer ice maker, located inside the freezer compartment — it is not the in-door icemaker used on many other Samsung models. This is a plastic tray-style ice maker with a 9-cube flex tray design, an 8-pin connector, and includes a motor for ice ejection, a water valve to fill the mold, and a thermostat that senses temperature and signals when it's time to release the finished ice.
This complete assembly contains the entire ice maker and its housing. If the mold's coating is flaking, or internal components have stopped functioning, replacing the full assembly resolves both problems at once. Failure symptoms include the ice maker not producing ice, reduced ice production, or loud popping sounds coming from the ice maker during operation. It directly replaces DA61-03213B, DA97-07603B, DA97-05037D, DA97-07603A, 2688774, DA59-00294A, DA61-03213B, DA63-06415A, DA97-05037A, DA97-05037C, DA61-05227, AP5651755, ASM105616, PD00002034, PS5575313.
Quick Answer
The DA97-07603B Genuine OEM Samsung Refrigerator Ice Maker fixes Samsung and select Maytag refrigerators where the freezer ice maker has stopped producing ice, is making less ice than usual, or is making loud popping sounds during operation. 9-cube flex tray, 8-pin connector. Replaces DA61-03213B, DA97-07603B, DA97-05037D, DA97-07603A, 2688774, DA59-00294A, DA61-03213B, DA63-06415A, DA97-05037A, DA97-05037C, DA61-05227, AP5651755, ASM105616, PD00002034, PS5575313. This is the freezer ice maker — it does not fit an in-door icemaker, and it is not a substitute for the DA97-07603C icemaker used on other models.
Common Problems This Part Fixes
- Ice maker has stopped producing ice entirely
- Ice maker producing less ice than it used to
- Loud popping sounds coming from the ice maker during operation
- Ice mold coating visibly flaking or deteriorating
- Ice maker cycling but not ejecting ice properly
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This refrigerator ice maker directly replaces the following OEM and cross-reference part numbers:
DA97-07603B, DA97-05037D, DA97-07603A, 2688774, DA59-00294A, DA61-03213B, DA63-06415A, DA97-05037A, DA97-05037C, DA61-05227, AP5651755, ASM105616, PD00002034, PS5575313
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This freezer ice maker is compatible with select Samsung refrigerators, and also fits select Maytag refrigerators built on the Samsung platform, spanning model series including RF220D, RF220N, RF221N, RF22A4, RF23HC, RF260BE, RF261BE, RF263TE, RF27T5, RF28HD, RF28HF, RF28R6, RF28T5, RF30HD, and RF323T, including specific model numbers such as RF220NCTABC/AAA-0001.
Note — freezer icemaker only, and not a substitute for DA97-07603C: This is a drop-in replacement for the freezer icemaker only. It will not fit an in-door icemaker used on many other Samsung models. It also replaces the earlier DA97-07603A version, but is not a suitable substitute for the DA97-07603C icemaker used on other models, despite the similar numbering. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure which icemaker your refrigerator needs.
Key Features
- Genuine Samsung OEM part — factory-specified mold design and cycling mechanism
- 9-cube flex tray design
- Includes motor for ice ejection, water valve for mold fill, and thermostat for temperature sensing
- Resolves "not making ice," "reduced ice production," and "loud popping sounds" symptoms
- 8-pin connector for a direct electrical fit
- Complete assembly — includes the ice maker and its housing
- Direct drop-in replacement for the freezer compartment icemaker
- Replaces DA61-03213B, DA97-07603B, DA97-05037D, DA97-07603A, 2688774, DA59-00294A, DA61-03213B, DA63-06415A, DA97-05037A, DA97-05037C, DA61-05227, AP5651755, ASM105616, PD00002034, PS5575313
- Compatible with Samsung and select Maytag refrigerators
- Genuine OEM replacement — guaranteed fit, materials, and performance
Product Specifications
| Part Number | DA97-07603B |
| Part Type | Refrigerator Freezer Ice Maker Assembly |
| Condition | Genuine OEM |
| Brand | Samsung |
| Tray Style | Plastic, 9-cube flex tray |
| Connector | 8-pin |
| Location | Freezer compartment (not an in-door icemaker) |
| Included Components | Ejection motor, water valve, thermostat, housing |
| Repair Difficulty | Easy — approx. 15 to 30 minutes |
| Quantity | 1 ice maker assembly |
| Compatible Brands | Samsung, Maytag |
Installation Notes
Frequently Asked Questions
My ice maker makes loud popping sounds. Is this the part I need?
Yes, this is a documented symptom of a failing ice maker assembly, alongside reduced or stopped ice production. If you're hearing unusual popping noises during the ice-making cycle, replacing the complete assembly addresses the underlying mechanical or electrical issue rather than trying to isolate and repair a specific internal component.
My refrigerator has an in-door ice maker. Will this part fit?
No. This DA97-07603B is specifically a drop-in replacement for the freezer compartment icemaker and will not fit an in-door icemaker used on many other Samsung refrigerator models. Check where your current ice maker is physically located — inside the freezer versus built into the refrigerator door — before ordering.
Is this the same as the DA97-07603C icemaker I've seen for other models?
No. While this part does replace the earlier DA97-07603A version, it is explicitly not a suitable substitute for the DA97-07603C icemaker used on other Samsung models, despite the similar numbering. Always confirm your full model number rather than assuming based on a close part number match.
Is this an OEM or aftermarket part?
This is a genuine OEM part, manufactured by Samsung to factory specifications — guaranteed fit, materials, and performance. It matches the original mold design, motor, water valve, and thermostat configuration of the freezer ice maker originally installed in your refrigerator.
