XPARTCO W11168740 Washer Water Valve (Cold Side)
Single-solenoid cold-water inlet valve for select Whirlpool-built top-load washing machines.
Product Description
The XPARTCO W11168740 Washer Cold Water Inlet Valve controls the flow of cold water entering compatible washing machines. When energized by the washer control, the solenoid opens the valve to allow cold water through the inlet hose and into the washer.
This is a quality XPARTCO aftermarket replacement part designed for select Whirlpool-built top-load washers.
Quick Answer
W11168740 is the cold-side washer water inlet valve. It uses a standard threaded hose inlet and a single-solenoid design. It replaces W10240949, WPW10240949, and W10921514 on compatible models.
Common Problems This Part May Fix
- Washer does not fill with cold water
- Cold water enters very slowly
- Washer fills with cold water only
- Leak near the rear cold-water connection
- Valve does not shut off completely
- Hot-water solenoid fails to operate
Replaces and Cross-References
Cross-reference numbers are provided for identification. XPARTCO is an aftermarket replacement brand and is not manufactured by Whirlpool.
Compatibility
Designed for select Whirlpool-built top-load washers sold under Whirlpool, Maytag, Kenmore, Amana, Estate, Roper, Inglis, KitchenAid, Crosley, and related brand names. Compatible model examples include:
Important: This is only a partial compatibility list. Hot- and cold-side valves can look similar but use different outlet arrangements, connectors, flow rates, and mounting points. Verify the complete washer model and original part number before ordering.
Key Features
- Quality XPARTCO aftermarket replacement
- Hot-side water inlet valve
- Single-solenoid design
- Standard threaded hose inlet
- Controls cold-water flow into the washer
- Replaces W10240949 and W10921514
Product Specifications
| XPARTCO Part Number | W11168740 |
| Brand | XPARTCO |
| Part Type | Washer Cold Water Inlet Valve |
| Condition | New |
| Part Quality | Aftermarket Replacement |
| Valve Position | Cold Side |
| Solenoid Configuration | Single Solenoid |
| Application | Top-Load Washing Machine |
| Included | One Cold Water Inlet Valve |
Troubleshooting Guide
- Unplug the washer and close both water-supply valves.
- Confirm that the household cold-water valve is open and the inlet hose is not kinked.
- Inspect the inlet screen for sediment or blockage.
- Test the cold-water solenoid and verify that it receives voltage during a hot-fill command.
- Check the wiring, temperature selection, control board, and pressure system if the valve is not energized.
- Replace the valve if it leaks, remains open, is electrically open, or fails to pass water when energized.
Safety: Disconnect electrical power and shut off the water supply before service.
When Should You Replace This Part?
- The washer will not fill with cold water
- The valve leaks or will not close
- The solenoid has no continuity
- The valve remains restricted after the screen is cleaned
- The original valve body or hose threads are damaged
Installation Notes
- Mark the cold-water hose and wire location before removal
- Transfer outlet hoses and clamps to their original positions
- Check all connections for leaks before reinstalling panels
- Test cold-water filling after full reassembly
Shop With Confidence
Verify the complete washer model and original valve number before ordering. Our compatibility team can help determine whether XPARTCO W11168740 is correct for your appliance.
